760MM Foil PVC UV Stack Six Color High Speed Ci Flexo Printing Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Flexographic Printer | Printing Speed: | 150-180m/min |
|---|---|---|---|
| Color: | Customizable | Machine Type: | High Speed Flexo Printing Machine |
| High Light: | High Speed Ci Flexo Printing Machine,760MM Ci Flexo Printing Machine,Ci Printing Machine |
||
Six Color High Speed Central Drum Flexographic Priting Machine
Machine Type: Central impression type, film supported by the big drum, never leaving between colors, so register better
Machine Structure: Parts are commonized for availability, low-wear design
Dryer: Hot wind dryer, automatic temperature controller for printing material dry safety, provided by the separated heater box.
Doctor Blade: Chamber doctor blade for High Speed and Quality Printing.
Transmission: High Performance vector motor, buttons are placed in multiple placed for the machine start, up speed, down speed, stop, which makes operators more convenience. After machine start, it reach the preset speed automatically.
Rewinder driving: High Performance ac motor, low friction cylinder for stable web tension.
Color Registration: Electric motor type, Push buttons by up, down, left and right only.
Machine Main Parameter:
| MODEL | DY-CI-6600 | DY-CI-6800 | DY-CI-61000 | DY-CI-61200 | ||
| MATERIAL |
PAPER 15-300g/m2, NONWOVEN 15-120G, PVC:10-120um, OPP:10-100um, PE15-150um, NY:10-12um, PET:10-100um, CPP:10-100um |
|||||
| MAX MATERIAL WIDTH | 600MM | 800MM | 1000MM | 1200MM | ||
| MAX PRINTING WIDTH | 560MM | 760MM | 960MM | 1160MM | ||
| COLORS | 6 COLOURS | |||||
| PRINTING LENGTH | 300-1000MM | |||||
| CENTRAL DURM DIA | 1200MM | |||||
| MACHINE SPEED | 200M/MIN | |||||
| PRINTING SPEED | 150-180M/MIN | |||||
| PRINTING PRECISION | +/-0.1MM | |||||
| PLATE THINCKNESS | 1.7MM ( If Different Thickness, Please Note Us ) | |||||
Sample of Pritnting
Every machine will be tested before shipment. And send video, sample, and container load photo one by one.
Machine In the Facotry
FAQ---------------------------------------------------------------------------------------------------------------------------------------------
1.Q:Are you machinery factory or trading company
A:We are machinery factory,and also have one trading company
2.Q:Where is your factory located?
A:We are located Rui`an City,Zhejiang Province,China
From SHANGHAI by air is 40mins,by train is 4hours.
From GUANGZHOU by air is 2hours.
3.Q:How many years warranty?Can you teach us?
A:In usually is one years warranty.
4.Q:What's the payment method?
A:We can accepted T/T,L/C,Western Union,Moneygram ETC.
