PLA Biodegradation MLDPE Rotary Die 3 Layer Blown Film Extruder

Large Image : PLA Biodegradation MLDPE Rotary Die 3 Layer Blown Film Extruder Get Best Price

Product Details:

Place of Origin:	ZHEJIANG CHINA
Brand Name:	DINGYI
Certification:	CE
Model Number:	DY/HL

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Price:	Negotiable
Packaging Details:	Wooden And Soft Packing
Delivery Time:	60Days
Payment Terms:	L/C, T/T
Supply Ability:	100 Sets Per Year

Contact Now

Detailed Product Description

Type:

Three Layer Film Blowing Machine

Material:

HDPE LDPE LLDPE MLDPE

Automatic:

Warranty:

1 Year

High Light:

3 Layer Blown Film Extruder

Rotary Die Blown Film Extruder

mLDPE Co Extruder Machine

Three Layer Co-Extrusion Film Blowing Machine ( Rotary Die )

Suitable LDPE.HDPE.LLDPE MLLDPE To make shopping bags ,garbage bags,fedex bag etc.
Operation with remote monitoring interface makes the width changed easily,conveniently and simple

Machine Specification And Feature:
1. Rotary die head
2. Fast screen changer
3. Double winder with inverter control
Need any specification. Just feel free to contact with us.

MODEL	DY-3L45	DY-3L50	DY-3L55	DY-3L65
SUITABLE MATERIAL	LDPE LLDPE HDPE
FILM WIDTH	600-1000mm	800-1500mm	1000-1800mm	1500-2500mm
FILM THICKNESS	0.03-0.20mm	0.03-0.20mm	0.05-0.20mm	0.05-0.15mm
MAX. SQUEEZING AMOUNT OF SINGLE SCREW ROD	80-130kg/hr	120-190kg/hr	150-180kg/hr	180-260kg/hr
EXTRUDER
SCREW DIAMETER	φ45/50/45	φ50/55/50	φ55/60/55	φ65/70/65
SCREW L/D LENGTH	30:1
SCREW MATERIAL	SACM-645/38 CRMOALA
CYLINDER MATERIAL	SACM-645/38 CRMOALA
CYLINDER COOLING	370×2	550×2	550×3	550W×4
DRIVING MOTOR	18.5/22/18.5Kw	22/30/22Kw	30/37/30Kw	37/45/37Kw
TEMPERATURE CONTROL	3	4	4	4
AVERAGE POWER-CONSUME	55Kw	68Kw	90Kw	130Kw
TYPE OF DIE
DIE SIZE	φ250/200	φ300/350	φ400/350	φ500
TEMPERATURE CONTROL	3	3	4	4
AIR RING	1	1	1	1
AIR BLOWER	5.5Kw	7.5Kw	7.5Kw	11Kw
TAKE-UPUNIT
ROLLER WIDTH	φ165×1100mm	φ165×1600mm	φ180×2000mm	φ220×2600mm
EFFECTIVE WIDTH	1000mm	1500mm	1800mm	2500mm
TAKE-UP SPEED	10-65m/min	10-65m/min	10-65m/min	10-40m/min
TAKE-UP MOTOR	1.5Kw	1.5Kw	2.2Kw	2.2Kw
HEIGHT ADJUSTABLE TYPE	700mm
WINDING UNIT
WINDING MOTOR	10N.m	16N.m	20N.m	30N.m
WINDING SPEED	10-65m/min	10-65m/min	10-65m/min	10-65m/min
OVERALL DIMENSION(L×W×H)	6.5×5.5×6.5m	7.5×5.8×7.5m	7.8×6.4×7.5m	8.5×7.2×10m
